Physical Pitch(mm)                                 7.62
Physical Pitch Density(Pixels/m2)         27222
Pixel configuration                   SMD3528/5050
Brightness(cd/m2)                                  1200
Module size(mm)                              244*122
Physical pixel/module                         32*16
Supply Voltage                          AC220/110V
Max Power Consumption                    700W/m2
Average Power Consumption               210W/m2
Operating Temperature                  -20 ~ +50
Operating Humidity                       10%~90%
Horizontal Viewing Angle                       160
Vertical Viewing Angle                           120
Grey Scale                                               4k
Display Colors                       4096Billion
Viewing Distance(min,max)                4~80m
Refresh Rate(Frame per Second)            180HZ
